M28s M28b shear beam Load Cell
General Details
Features
- M28S-CE
- M28B-OIML/NTEP
- Capacity up to 10000kg
- Stainless steel material
- Optional rubber pads for leveling feet
- Default cable length is 6m, diameter is 5mm
(Optional customized longer cable) - Interchangeable with below models: Tedea-Huntleigh* 3410/3411,3510, Revere*9123, ACB, Sensortronics*65083, Zemic* B8D, Flintec* SB9, Celtron*SEB
Models
| Part No. | 120128 | 120129 | 120130 | 120131 | 120132 | 120133 | 120134 | 120135 | 120136 |
| M28S | 100kg | 250kg | 500kg | 1000kg | 1500kg | 2000kg | 2500kg | 5000kg | 10000kg |
| Part No. | 120137 | 120138 | 120139 | 120140 | 120141 | 120142 | |||
| M28B | 250kg | 500kg | 1000kg | 2000kg | 5000kg | 10000kg | |||
| Part No. | 120143 | 120144 | 120145 | 120146 | 120147 | 120148 | 120149 | 120150 | 120151 |
| M28B | 500lb | 1klb | 2klb | 4klb | 5klb | 7.5klb | 10klb | 15klb | 20klb |
| Class | C3 | ||||||||
| IP | IP67 | ||||||||
Techical Info
Capacity
250-5000kg
Sensitivity
3.0 ± 0.008mV/V
Accurace
C3 | C4 | C5
Non-Linearity
0.02%FS
Non-Repeatability
0.01%FS
Creep (30 Min)
0.02%FS
Zero Balance
± 1% Emax
TE Zero
0.018%FS/10℃
TE Span
0.014%FS/10℃
Input Resistance
350 ± 3.5Ω
Output Resistance
350 ±3.5Ω
Insultation Resistance
≥5000mΩ
Opearting Tem Range
-35…65℃
Safe Load
150% F.S.
Ultimate Overload
300% F.S.
Recommended Excitation
5-12VDC
Protection:
IP67
Order Enquiry
Contact form description text
Approvals
OIML and NTEP and CE
