M17P Stainless Steel IP68 and IP69K Load Cell
17-4Ph stainless steel material and fully welded construction, comprehensive mounting holes, with IP68 | IP69K protection and capacity up to 500kg.
M17P Stainless Steel IP68 and IP69K Waterproof Load Cell, perfect for waterproof weighing platform and waterproof scales.
17-4Ph stainless steel material
Fully welded construction
Comprehensive mounting holes
IP68 | IP69K protection
Capacity up to 500Kg
Recommended platforms:
250x250mm to 800x800mm
default of 3m Cable dia 5mm
Customized cable available
| Part No. | 120093 | 120094 | 120095 | 120096 |
| M17P | 10kg | 20kg | 50kg | 100kg |
| Part No. | 120097 | 120098 | 120099 | 120100 |
| M17P-L | 100kg | 200kg | 300kg | 500kg |
| Class | C3 | |||
| IP | IP68 & IP69K | |||
Capacity
10 -500kg
Sensitivity
2.0 ± 0.2mV/V
Accurace
C3 | C4 | C5
Non-Linearity
0.017%FS
Non-Repeatability
0.01%FS
Creep (30 Min)
0.02%FS
Zero Balance
± 1% Emax
TE Zero
0.017%FS/10℃
TE Span
0.014%FS/10℃
Input Resistance
350 ± 3.5Ω
Output Resistance
350 ±3.5Ω
Insultation Resistance
≥5000mΩ
Opearting Tem Range
-35…65℃
Safe Load
150% F.S.
Ultimate Overload
300% F.S.
Recommended Excitation
5-12VDC
Protection:
IP68
Contact form description text
CE and NTEP and OIML
