CSD crane scale
Rugged Structure
Two different materials: Aluminum alloy – till 5000kg. Alloy steel – 5000kg more. With aluminum suitcase. High accuracy of 0.05%F.S.. LCD display with backlight. Two setpoints for weight limit. Long working time ≥ 40 hrs. – with 3 x AA batteries. Multi-units: kg | ton | N | KN. Calibration with remote control. 4 Direct keys on the scale. Palm hold indicator E380. Zero/Tare function. Peak hold function. Overload warning. Power saving mode.
Accessories
Wireless remote display – MDS5FM. Multi-channel E380-4 indicator. – up to 4 scales work together. Bluetooth output – for Hscaler2. Bluetooth printer – RP01.
Models
| Part No. | 100620 | 100621 | 100622 | 100623 | 100624 |
| Models | CSD1k | CSD2k | CSD3k | CSD5k | CSD10k |
| Capacity | 1000kg | 2000kg | 3000kg | 5000kg | 10000kg |
| Division | 500g | 1kg | 1kg | 2kg | 5kg |
| Weight | 5.8kg | 7.7kg | 7.7kg | 10.1kg | 27kg |
| Part No. | 100625 | 100626 | 100627 | 100628 | 100629 |
| Models | CSD20k | CSD30k | CSD50k | CSD100k | CSD200k |
| Capacity | 20000k | 30000kg | 50000kg | 100000kg | 200000kg |
| Division | 10kg | 10kg | 20kg | 50kg | 100kg |
| Weight | 63kg | 66kg | 88kg | 195kg | – |
Power
3 x AA batteries
Capacity
1000 – 200000kg
Accuracy
Class III
Housing
Aluminum alloy – till CSD5K
Alloy steel – CSD10k and more
IP Rate
IP54
Safety Load
125% F.S.
Ultimate Load
400% F.S.
Display
1” LCD (30mm)
Unit
kg | lb | N | KN
Zero Range
4% F.S.
Tare Range
20% F.S.
Output
Bluetooth (optional)
Operating Temperature
-10°C – 40°C
Remote Control Distance
> 15m
